Specifications:

  • Wood Only

  • 3HP

  • Rip Capacity: 52”

  • 45° Angle capacity

  • 10” blade

  • Max cutting depth 3”

  • 4,000 RPM

Safety:

  • Always wear safety glasses and hearing protection when operating.

  • Never wear gloves or long sleeves when operating.

  • Secure any loose jewelry, long hair, hoodie strings, and other dangling objects.

Rules:

  • Do not cut steel or other metals with this saw.

  • Do not cut heavily carbonized (burnt) wood with this saw.

  • Do not cut purpleheart wood on this saw.

  • Do not cut anything other that wood with this saw.

  • Do not cut crosscuts with the fence, only with the crosscut sled is it safe.

  • Do not use without Blade Guard or riving knife installed.

  • Ask for assistance for changing the blade.

  • Never touch the blade when the saw is powered on.

  • Only cut one piece at a time.

  • Do not cut pieces smaller than 6” long.

  • Do not cut through wood knots, splits, or other defects if possible.

  • Do not start saw with material touching the blade.

  • Do not put liquid near the metal tabletop surface.

  • If the brake system engages due to the member not following instructions, Breva will charge that member $200 to replace the brake system and the saw blade.

Step-by-Step Guide:

  1. Check for metal in wood with metal detector.

  2. Check for moisture content of the wood prior to cutting using our moister meter. Anything over 15% moisture cannot be cut on this saw.

  3. Adjust angle of blade as needed. Only make adjustments when power is off and machine is not moving.

  4. Adjust the fence as needed. Make sure it is locked in position before starting

  5. Clear the work area of debris, obstructions, or tripping hazards. Ensure adequate lighting and ventilation. Make sure no one is in the way of the saw or standing directly behind it.

  6. Turn on Dust Collection System.

  7. Locate and use push sticks and/or a featherboard. Position your push stick halfway between the saw blade and fence when cutting. Only position featherboards in front of the blade, never in line with or behind the blade.

  8. Setup a roller stand if you need to support the board on the back end while cutting.

  9. Verify you can hold your piece without putting your hands in the blade zone.

  10. Use a sled for cross cuts. Do NOT cut cross cuts on the table saw without it. Doing so is extremely dangerous.

  11. Adjust the blade height to just clear the material being cut to minimize exposure and reduce the risk of injury.

  12. Stand in a stable position with feet shoulder-width apart while operating the table saw. Stand to the left of the blade.

  13. Allow motor to reach full speed before cutting. Do not start saw with material touching the blade.

  14. Cut slowly and smoothly, keeping your hands away from blade at all times.

  15. Push material all the way through the full length of the blade before letting go of material.

  16. Wait for the saw to stop moving completely and remove hand from trigger before removing material.

  17. Turn saw off between cuts.

  18. Clear any debris or sawdust from the table after use using a dust pan and hand broom.
